Congestive Heart Failure and Pulmonary Edema

Etiology

There are many causes of heart failure, the most common of which is coronary artery disease in the US. The importance of identifying the risk factors for heart failure is that heart failure is preventable.  In recognition of the preventable nature of the condition, the American College of Cardiology and the American Heart Association have modified their classification schemes so that patients currently without any structural abnormalities are identified early and treated appropriately. Treatment of systolic and diastolic hypertension concurrently in alignment with contemporary guidelines reduces the risk of heart failure by approximately 50%.[1]

Risk Factors for Heart Failure

• Coronary artery disease (CAD)
• Connective tissue disorders (ie, rheumatoid arthritis, scleroderma, systemic lupus erythematosus)
• Endocrine disorders (ie, diabetes mellitus, thyroid function disorders, growth hormone deficiency)
• Hypertension
• High-output conditions (ie, anemia, Paget disease)
• Valvular heart disease
• Metabolic causes (ie, obesity)
• Myocarditis (ie, secondary to HIV and AIDS, medications, or viruses)
• Infiltrative disorders (ie, amyloidosis, sarcoidosis)
• Peripartum cardiomyopathy
• Stress cardiomyopathy (Takotsubo)
• Valvular heart disease
• Medications (ie, amphetamines, anabolic steroids)
• Tachycardia induced cardiomyopathy
• Toxins (ie, cocaine, alcohol)
• Nutritional deficiency (ie, L-carnitine deficiency, thiamine) [1]

Risk Factors for Acute Heart Failure and Flash Pulmonary Edema

Acute heart failure is the worsening of heart failure symptoms to the point that the patient requires intensification of therapy and intravenous treatment. Acute heart failure can be dramatic and rapid in onset, such as flash pulmonary edema, or more gradual with the worsening of symptoms over time until a critical point of decompensation is reached. For those with a history of preexisting heart failure, there is often a clear trigger for decompensation.[3][4]

Potential Triggers of Acute Decompensated Heart Failure and Flash Pulmonary Edema

• Arrhythmia
• Acute coronary syndrome (CAD)
• Infection
• Worsening hypertension (ie, hypertensive crisis)
• Medication non-adherence
• Acute renal artery stenosis
• Left ventricular diastolic dysfunction
• Obstructive sleep apnea
• Stress (Takotsubo) cardiomyopathy [3][4]

Epidemiology

Heart Failure is a major public health problem. It is now the most common cause of hospitalization in the US among patients 65 years and older, and approximately 91,5000 new cases of heart failure are diagnosed each year in the US. The increasing prevalence of heart failure is most likely secondary to the aging of the population, increased risk factors, better outcomes for acute coronary syndrome survivors, and a reduction in mortality secondary to improved management of chronic conditions. Incidence rates for heart failure increase with age for both sexes.[1][2][3][5]

The lifetime risk of developing heart failure for those over age 40 years residing in the US is 20%. The risk and incidence of heart failure continue to increase from 20 per 1000 people aged 60 to 65 years to over 80 per 1000 people over age 80. There are also differences in risk for heart failure based on the population, with African Americans having the highest risk and greater 5-year mortality for heart failure than the white population in the US. The European Society of Cardiology states that the prevalence of heart failure is 1% to 2% and rises to greater than 10% in the over-70 population.[1][3]

Heart Failure Statistics

• Heart failure survival has improved over time, yet the absolute 5-year mortality rates from diagnosis for heart failure have remained at 50%
• Heart failure is the number 1 diagnosis among all hospitalizations, and the cost of annual heart failure care exceeds $30 billion every year.
• Most of the cost spent on heart failure patients is for hospitalizations and readmissions.[1]

Acute Heart Failure

Although consensus guidelines tend to use the term heart failure to refer to those with established chronic disease, acute heart failure is defined as a more rapid onset of signs and symptoms or the gradual worsening of chronic symptoms that necessitate intravenous treatment. Acute heart failure exacerbation that requires hospitalization tends to occur in the more elderly population, with a mean age of 79 years old and a slightly higher preponderance of women affected than men.[1][2][3] Data from the UK National Heart Failure Audit show mortality rates of approximately 10% during the index admission, 30-day postdischarge mortality of 6.5%, and 1-year mortality of 30%.[3]

Pathophysiology

Different cardiovascular or metabolic abnormalities can cause heart failure, but in most patients, the clinical symptoms are secondary to left ventricular dysfunction. In cases caused by left ventricular dysfunction, the ejection fraction may be preserved or compromised. The ejection fraction is important because most clinical trials select patients based on the ejection fraction percentage and use the ejection fraction data to help guide therapy. In contrast, pulmonary edema associated with acute decompensated heart failure is secondary to dysregulation of pulmonary fluid homeostasis and the forces that balance fluid movement into the alveolar space.[4][6]

History and Physical

Heart failure is mainly a clinical diagnosis. The presentation of heart failure may vary based on each patient; therefore, it is essential to consider the following during the history and physical:

• History: If the patient has a history of heart failure in the past, ask them if this is the same presentation as when they had previous episodes of heart failure or an acute decompensation.
• Symptom Causes: Consider noncardiac and other causes for the patient's symptoms. It is important to ensure that there is a broad differential diagnosis and to avoid anchoring bias, premature closer, and diagnostic inertia.
• Heart failure symptoms:
  • Increasing dyspnea (on exertion, on lying flat or at rest, exercise intolerance)
  • Increasing leg swelling, ascites, edema
  • Increased body weight -ask patients if they have been tracking their weight at home and if it has increased since their symptoms have become worse.
  • What are the patient's baseline symptoms, and are the current symptoms worse or similar to when they had previous heart failure exacerbations?
  • Palpitations, automatic implantable cardioverter-defibrillator (AICD) shocks (associated with worse prognosis)
  • Chest pain, fatigue
  • Duration of Illness, recent or frequent hospitalizations for heart failure
  • Medications or diet changes
  • Anorexia, cachexia, or early satiety (associated with worse prognosis)
  • Symptoms of transient ischemic attack (TIA) or thromboembolism (indicate a possible need for anticoagulation)
  • Social history and family history (to assess for possible familial cardiomyopathy, alcohol, or other cause
  • Travel history (exposure risk to some tropical diseases) [1][6]

Physical Examination[1][6]

The physical examination should include the following:

• Vital signs - assess blood pressure, heart rate, temperature, oxygen saturation, and respiratory rate. Vital signs are important in helping develop and refine the differential diagnosis and help the healthcare provider to better tailor the physical examination.
• Check patient weight – The patient's weight and BMI should be checked during each office visit. The information can be used to track response to treatment and the potential progression of heart failure or ADHF. Losing weight can also be a warning sign of worsening HF.
• Assessment of jugulovenous distension – Jugulovenous distension can be a marker for fluid overload. The patient should be lying at a 45-degree angle in bed to get an accurate assessment.
• Pulse - Assess the regularity and strength of the pulse
• Cardiac Examination
  • Extra heart sounds (ie, S3 is associated with a worse prognosis), murmurs
  • Size and location of maximal cardiac impulse (can suggest ventricular enlargement if displaced)
  • Presence of right ventricular heave
• Pulmonary Examination - Respiratory rate, rhonchi, rales (note: pleural effusions can mask reduce breath sounds, and rhonchi or rales may be less prominent)
• Abdominal examination - check for ascites, hepatomegaly, hepatojugular reflux
• Lower extremity examination - assess for peripheral edema and the temperature of skin (cool lower extremities may be suggestive of worse cardiac output) [1][6]

Evaluation

Classification of Heart Failure[1][6]

Classification is 1 of the key determinates of how to evaluate and treat heart failure. When a patient is in acute or decompensated heart failure, our focus is on expeditious identification and treatment of life threats. When evaluating chronic heart failure, different classification schemes are available. The classification scheme used to categorize the type and degree of heart failure is based on the presentation and affect the treatment and prognosis of the condition. Heart failure classification schemes are generally based on 1 of the following:

1. Anatomic findings (ie, heart failure with different degrees of ejection fraction)
2. The chamber of the heart involved (including functional)
3. Symptoms of the patient

All heart failure patients should also be classified based on the ACCF/American Heart Association stages of heart failure, a New York Heart Association functional classification.[1][6]

ACCF/AHA Stages of Heart Failure

The ACC/AHA stages of heart failure are defined by the risk of heart failure, the presence of active heart failure, and whether structural heart disease is present. In general, the higher the classification, the greater the treatment and interventions that the patient may require.

• A  - No structural heart disease present, high risk for heart failure, and asymptomatic
• B  - Structural heart disease present, asymptomatic
• C  - Structural heart disease present and current or previous symptoms of heart failure
• D  - Heart failure that is refractory and requires specialized interventions [6]

NYHA Functional Classification of Heart Failure

The NYHA classification is a functional classification of heart failure and is based on how much the patients' symptoms limit their physical activity and to what degree physical activity can cause the person to become symptomatic. The grading scale is from I up to the most severe of grade IV where the patient is unable to carry on physical activity and has symptoms at rest.[6]

Diagnostic Tests

Testing for heart failure patients should be focused on the patient's symptoms, clinical suspicion, and the current and any pre-existing or current stage of heart failure. The ordering of multiple routine tests should be avoided in all heart failure patients. Basic tests that should merit consideration for all patients evaluated for heart failure are the following:

• Serum electrolytes and kidney function
• Complete blood count
• Lipid level
• Liver function tests
• Troponin level - if there is concern that myocardial injury is the cause of symptoms
• Thyroid-stimulating hormone
• An electrocardiogram should also be performed on all heart failure patients

Other tests that may be considered based on the severity and classification of the patient's condition are:

• Chest x-ray to assess for signs of pulmonary congestion or edema in acute decompensated heart failure
• Biomarkers - used to assess patients with more complex symptoms than acute heart failure (ie, B-type natriuretic peptide and N-terminal pro-B-type natriuretic peptide)

For further information on the recommendations for evaluating heart failure, please see the American Heart Association and New York Heart Association classification-based heart failure guidelines.[1][6][2]

Treatment / Management

Treatment of Acute Decompensated Heart Failure and Pulmonary Edema

The focus of treatment for patients with heart failure is dependent on the severity of the symptoms and the stage of heart failure. When patients are in acute decompensated heart failure or flash pulmonary edema, the most important focus for therapeutic interventions is the enhancement of hemodynamic status through the reduction of vascular congestion and improving preload, afterload, and myocardial contractility.[2]

In flash pulmonary edema, where there is a rapid onset of heart failure, the initial management and treatment goals are very similar to acute decompensated heart failure. Treatment options for acute decompensated heart failure and flash pulmonary edema are as follows:

1. ABCs - As with all patients, it is important to assess airway, breathing, and circulation in the initial evaluation and initiate appropriate management based on patient status. In decompensated heart failure, patients should be hooked up to cardiorespiratory monitoring, have IV access and oxygen administered if hypoxic or tachypnoeic, have ECG performed, and have labs drawn based on clinical suspicion and patient condition.
2. Diuretics - most patients presenting with heart failure have a form of volume overload. AHA and ACC guidelines recommend intravenous (IV) loop diuretic administration to treat fluid overload. IV administration is preferred over oral for diuretics to maximize the bioavailability of the medication and clinical effect. Furosemide is a common treatment for acute decompensated heart failure and flash-pulmonary edema because of its anti-vasoconstrictor and diuretic effects.[2][6]
3. Vasodilators - Patients with acute decompensated heart failure with HTN and acute pulmonary edema can benefit from treatment with vasodilators. Most vasodilators promote smooth muscle relaxation and vasodilatation to reduce preload and afterload through the cyclic guanine monophosphate pathway. Vasodilation relieves pulmonary vascular congestion and improves left ventricular preload and afterload. The common vasodilator medications used are Nitroglycerin and Sodium Nitroprusside.[2][6]
• Nitroglycerin can be given transdermal, sublingual, or intravenously, depending on the patient's condition. In acute decompensation or flash pulmonary edema, nitroglycerin is best given sublingually or intravenously to allow for titration of effect.[2][6]
• Sodium nitroprusside is only given intravenously. Patients with renal dysfunction treated with sodium nitroprusside may need to have their cyanide levels monitored. Check with your pharmacist about guidelines for monitoring cyanide levels.[2][6]
4. Ionotropic Medications - Additional treatment options for patients in cardiogenic shock or who have signs of end-organ dysfunction secondary to hypoperfusion. Inotropes should only be used as a treatment adjunct in acute decompensated heart failure since data from the ADHERE registry suggest increased mortality with use. Dobutamine and MIlrinone are 2 inotropes that are more commonly used. Dobutamine is preferable for beta-blocker-naive patients, while Milrinone is preferred for patients previously taking oral beta blockers who experience acute decompensation.[2][6]
5. CPAP/BIPAP - Continuous Positive Airway Pressure (CPAP) and Bilevel Positive Airway Pressure (BIPAP) are noninvasive methods of respiratory support to treat respiratory insufficiency secondary to pulmonary vascular congestion and pulmonary edema. The use of CPAP and BIPAP has reduced the need for intubation and mechanical ventilation in heart failure patients with acute respiratory decompensation. In situations where CPAP and BIPAP are ineffective in improving the patient's respiratory status, consider early intubation and mechanical ventilation to help prevent further decompensation and progression of symptoms.[7][8]
6. Coronary revascularization - When performed in appropriately selected patients, revascularization can reduce mortality and morbidity by improving diastolic and systolic dysfunction. According to the American Heart Association 2013 CHF guidelines, coronary artery revascularization may be indicated as an intervention for heart failure patients with angina, LV dysfunction, and CAD. Interventional cardiology should be consulted early for patients according to AHA recommendations.[2][6]
7. Admission to inpatient service for further treatment and evaluation. Patients being treated for flash pulmonary edema should be admitted to the hospital with the level of monitoring and care appropriate for each case. For select patients with acute decompensated heart failure, it may be possible to treat them at home depending on the severity of symptoms[9]
(B3)

The Medical Management of Heart Failure – Risk Factor Modification and Prevention of Acute Decompensation

While acute decompensated heart failure and flash pulmonary edema can be dramatic and require intensive care and aggressive therapy, the main focus of heart failure management is on helping prevent the progression of the disease and mitigate episodes of acute exacerbation. The American Heart Association and the New York Heart Association stages of heart failure are what medical practitioners often use to guide the evidence-based treatment of heart failure. Treatment of early stages of chronic heart failure usually focuses on risk factor modification, and as the disease process progresses, it starts to include more aggressive interventions.

• Risk factor modification
  1. Dietary and lifestyle changes, such as decreased salt intake, reduced obesity, and smoking cessation
  2. Tighter control and management of hypertension, diabetes dyslipidemia, and other chronic diseases that can exacerbate CHF

• More aggressive intervention for those with a higher degree of CHF
  1. Echocardiography for patients with a higher risk of left ventricular ejection fraction reduction
  2. Implantable cardiac defibrillator placement, when indicated in patients with ischemic cardiomyopathy at high risk of sudden death

For further information on the medical management of chronic heart failure, please refer to the American Heart Association and New York Heart Association guidelines.[1][6][2](B3)

Advanced Treatment Strategies for End-Stage Congestive Heart FailureFor select patients with end-stage heart failure, which is refractory to other treatment strategies, the option of mechanical circulatory support and cardiac transplantation should be considered. Mechanical circulatory support, for example, a left ventricular assist device, is often used as a bridge therapy until a heart transplant is available. In certain situations, mechanical circulatory support is utilized as destination therapy. For patients who are not candidates for mechanical circulatory support or cardiac transplantation, palliative care and continuous inotropic support should be considered and discussed with the patient (See Image. Congestive Heart Failure).[1][10]

Differential Diagnosis

When patients present with acute decompensated heart failure or flash pulmonary edema, there are many different diagnoses to consider based on the risk factors for heart failure alone. It is also important to consider other potentially life-threatening causes of heart failure.

1. Sepsis - Septic patients are at risk of multiorgan system failure. Approximately 1 out of 3 patients with sepsis present with reversible left ventricular systolic dysfunction reduced ejection fracture, and 1 out of 2 patients with sepsis have left ventricular or right ventricular diastolic dysfunction. The cardiac dysfunction associated with sepsis can result in significantly increased mortality. Left ventricular diastolic dysfunction is associated with an increased mortality risk of 80%, and right ventricular diastolic dysfunction is associated with a 60% increased mortality.[11]
2. Acute respiratory distress syndrome (ARDS) is characterized by acute respiratory failure and diffuse pulmonary infiltrates, which could potentially mimic flash pulmonary edema.[11]
3. Neurological causes - Hemispheric and hippocampal brain infarcts are associated with heart failure and sudden cardiac death. Infarct of certain areas of the brain tissue can result in a sympathetic storm, and loss of vasomotor homeostasis precipitates neurogenic pulmonary edema (see Image. Key Features in the Pathophysiology of Neurogenic Pulmonary Edema).[12]
4. Pulmonary embolism - While a massive pulmonary embolism can cause acute cardiac dysfunction secondary to obstruction of blood flow, post-pulmonary embolism syndrome may also present with heart failure-type symptoms. Post pulmonary embolism syndrome, reduced exercise tolerance has been associated with reduced left ventricular ejection fraction, arrhythmia, valvular dysfunction,n and left ventricular diastolic dysfunction.[13]
5. Acute coronary syndrome - Acute coronary syndrome or myocardial infarction is a common cause of acute decompensated heart failure.

Prognosis

The diagnosis of heart failure alone can be associated with a mortality rate greater than many cancers. Despite advances made in heart failure treatments, the prognosis of the condition worsens over time, resulting in frequent hospital admissions and premature death. One recent study showed that patients recently diagnosed with new-onset heart failure had a mortality rate of 20.2% at 1 year and 52.6% at 5 years. The 1- and 5-year mortality rates also increase significantly based on patient age. Another study showed that the 1- and 5-year mortality for patients at 60 years old is 7.4% and 24.4%, and for patients at 80-year-olds is 19.5% and 54.4%. The mortality rates were similar when evaluated across different cardiac ejection fractions.[5][10][14]

The prognosis is worse for heart failure patients who are hospitalized. Heart failure patients commonly require repeat hospitalizations and develop an intolerance for standard treatments as the disease progresses. Data from U.S. Medicare beneficiaries hospitalized during 2006 showed 30-day and 1-year mortality rates postadmission of 10.8% and 30.7,% respectively. Mortality outcomes at 1 year also demonstrate a clear relationship with age and increase from 22% at 65 years old to 42.7% for patients aged 85 years and older.[5][10]

Complications

 Potential Complications of Heart FailureWorsening clinical status despite aggressive therapy

• Associated renal impairment and organ dysfunction can compromise heart failure treatment efforts
• Recurrent hospitalizations for heart failure or, most commonly, associated co-morbidities, with resultant financial and personal costs to patients and families
• The progressive loss of ability to carry out activities of daily life
• Increased morbidity and mortality from the date of the patient's initial diagnosis of heart failure [1][5]
